Rock Breaker 3200A
Operating Weight
2550 Kg
Oil Flow
180 - 240 lpm
Tool Diameter
155 mm
Operating Pressure
160 - 190 bar
Impact Rate
300 - 450 BPM
Return Line Pressure
10 bar
Overview
DOZCO Rock Breaker 3200A is a high-performance attachment designed for heavy-duty applications such as primary/secondary breaking and tunneling. With its robust construction and advanced features, it delivers superior power and reliability. Engineered for excavators in the 28-36 tons class, the DOZCO Rock Breaker 3200A offers exceptional rock breaking capabilities. Whether you’re working on construction projects or involved in tunneling jobs, this attachment ensures efficient and effective rock breaking operations. Its durable design and precision control make it a reliable choice for demanding rock breaking tasks in various industries.
Rock Breaker 3200A Specifications
| Specifications | Rock Breaker 3200A | |
|---|---|---|
| Operating Weight* | Box | 2550 Kg |
| Side | - | |
| Top Split | 2473 Kg | |
| Height (Incl. Tool) | Box | 3114 mm |
| Side | - | |
| Top Split | 2770 mm | |
| Tool Diameter | 155 mm | |
| Tool Length | 1350 mm | |
| Optimal Oil Flow | 180 - 240 lpm | |
| Setting Pressure | 220 bar | |
| Operating Pressure | 160 - 190 bar | |
| Return Line Pressure | 10 bar | |
| Impact Rate | 300 - 450 BPM | |
| Bottom Plate Thickness (HB) | 60 mm | |
| Hose | In & Out | 1 1/4" |
| Control Valve Type | Internal | |
| Applicable Carrier | 28.0 - 36.0 ton | |
| 2 Stroke Control | No | |
| Accumulator | Yes | |
| Auto Greasing | Optional | |
| Anti Blank Firing (ABF) | No | |
* The operating weight include the MC+ Body+Tool weight
* The above specifications are subject to change without prior notice for the quality enhancement.
Features at a Glance
- Reliable And Durable Design
- Easy to Maintain
- Easy to Operate
Reliable And Durable Design
- Reinforced Body for greater reliability.
- Newer Accumulator design for higher efficiency.
- Larger Piston Diameter for increased impact energy.
- Improved Power / Weight ratio to maximise Productivity.
- Lower operating cost
Easy to Maintain
- Maintenance friendly.
- Economical Maintenance.
- Ring Bush – Combined Bush for less maintenance cost and more durable.
- Inspection Window – Easy access for inspection of Through Bolts
Easy to Operate
- User friendly.
- Light, simple, and smooth operation.
- Easy to use, manageable.
- Reinforced Body for greater reliability.
- Newer Accumulator design for higher efficiency.
- Larger Piston Diameter for increased impact energy.
- Improved Power / Weight ratio to maximise Productivity.
- Lower operating cost
- Maintenance friendly.
- Economical Maintenance.
- Ring Bush – Combined Bush for less maintenance cost and more durable.
- Inspection Window – Easy access for inspection of Through Bolts
- User friendly.
- Light, simple, and smooth operation.
- Easy to use, manageable.
